Lukas LC 99 - 11 Technical Data

22
Becauseallvaluesaresubjecttotolerances,theremaybeminordi󰀨erencesbetweenthe
dataforyourdeviceandthedatainthefollowingtables!
11. Technical data
* 1MPa=10bar
** Volumeofhydraulicuidrequiredinthehandpumptooperatethedevice
NOTE:
The following tables contain only the technical data required for standard
acceptance.
AdditionaldataconcerningyourunitcanbeobtainedfromLUKASonrequest.
Device type LC 99
Item number 81-85-10
Dimensions L x W x H
(w/o connection hoses)
[mm] 305x140x123
[in.] 12.0 x 5.51 x 4.84
min. cutting opening
[mm] 38
[in.] 1.50
max. cutting force
(rear end
of cutting surface)
[kN] 77
[lbf.] 17310
weight incl. hydraulic
uid
[kg] 3.0
[lbs.] 6.61
max. operating pressure
[Mpa]* 70
[psi.] 10000
volume
(of hydraulic uid)
[cm³] ** 46
[gal.-US] 0.012
coupling system Flat-Facequick-disconnectcoupling
