Lukas LC 99 - Component Replacements

18
9.3.2 Flat Face quick-disconnect coupling
Thequick-disconnectcouplingsmustbereplacedif:
- thereisexternaldamage,
- thelockdoesnotwork,
- hydraulicuidcontinuestoleakinthecoupledand/oruncoupledstate.
WARNING / CAUTION / ATTENTION!
Neverrepaircouplings:theymustbereplacedbygenuineLUKASparts!
Procedure:
1. Dismantlethecouplingfromtheswivelscrewconnectionofthecutter.
2. Installanewcouplingontheswivelscrewconnectionofthecutterandtightenwitha
torqueofM
A
=45Nm(33.2lbfxft)
A
=45Nm(33.2lbfxft)(use Teon tape).
9.3.4 Decals
Alldamagedand/orillegiblelabels(safetynotices,typeplate,etc.)mustbereplaced.
Procedure:
1. Removedamagedand/orillegibledecals.
2. Cleansurfaceswithacetoneorindustrialalcohol.
3. A󰀩xnewdecals.
Takecaretoa󰀩xthelabelsinthecorrectpositions.Ifthisisnolongerknown,youshouldask
yourauthorisedLUKASdealerorcontactLUKASdirectly.
9.3.3 Replacing the protective cover
- Removeroundedheadscrew
- Removeoldprotectivecover
- Fitnewprotectivecover
- RetightentheroundedheadscrewwithM
A
=0.5Nm(0.37lbfxft).
