4.4 Operating movement controls
Thepistonmovementiscontrolledbythestargripontheattachedvalve(seeillustrationbelow).
Stargrip
5.1 Battery or power supply for eDRAULIC device
5. Operation
Commissioning
Beforeinitialoperation,thebattery(whereused)oftherescuedevicemustbefullyloaded,
usingtheexternalcharger.
4.3 Hydraulic circuit diagram
A
B
cutting
opening
Belowasimpliedhydraulicramrepresentingthetoolisdepicted.
A=toolB=stargripvalve
