Lukas S 312 E2 - Page 34

34
Manufacturer
Name and type of the device
LUKASHydraulikGmbH
S377E2(90-20-23)
Classicationgiven
Type
Cutter opening
[mm]
Classication
based on
the minimum
performance of
the cutter
Dimensions [Kg]
(measured to one
decimal place)
Performance
of the cutter
206 I 19,3 1I-2J-3I-4J-5J
Prole type →
1 Round material 2 Flat material 3 Round tube 4 Square tube 5 Rectangular tube
Category
letter ↓
A ≥14 30x5 21,3x2,3
B ≥16 40x5 26,4x2,3
C ≥18 50x5 33,7x2,6 35x3
D ≥20 60x5 42,6x2,6 40x4 50x25x2,5
E ≥22 80x8 48,3x2,9 45x4 50x30x3,0
F ≥24 80x10 60,3x2,9 50x4 60x40x3,0
G ≥26 100x10 76,1x3,2 55x4 80x40x3,0
H ≥28 110x10 76,1x4,0 60x4 80x40x4,0
I ≥32 120x10 88,9x4,0 60x5 80x40x5,0
J ≥36 130x10 88,9x5,0 70x4 100x50x4,0
K ≥40 140x10 101,6x4,0 70x5 100x50x5,0
[mm] [mm] [mm] [mm] [mm]
