INFRATHERM pyrometers IS 5 · IS 5-LO · IGA 5 · IGA 5-LO
57
AARsX
Bit 1 = 1 gain = 0 Æ no P-control
Bit 0 = 1 gain Æ on/off controller
X = 0 or 1 Æ deactivates / activates the controller
starting self-tuning: AARt
AARtXXXX
Starts self-tuning algorithms
XXXX new set point (comp. Xs) and self-tuning-start
Note: PID-controller: at °F setting
X
s
Desired temperature in °F x 10 R
p
Desired temperature output is °F x 10
Y
i
Reading controller output and actual value, R
t
Self tuning with take over of controller output in °F x 10
actual value in °F x 10
Note: the letter ”l” means the small type of “L”
Additional instruction for the RS485 interface:
Requirements to the master system during half-duplex operation:
1. After an inquiry, the bus should be switched into a transmission time of 3 bits
(some older interfaces are not fast enough for this).
2. The pyrometer's response will follow after 5 ms at the latest.
3. If there is no response, there is a parity or syntax error and the inquiry has to be repeated.
After receiving the response, the master has to wait at least 1.5 ms before a new command can be entered.
15 Reference numbers
15.1 Reference numbers of instruments
IS 5; IGA 5
Type Temperature range targeting
light, RS232
view finder,
RS232
targeting
light, RS485
view finder,
RS485
IS 5 MB 20: 600 ... 2000°C 3 857 150 3 857 170 3 857 160 3 857 180
IS 5 MB 25: 800 ... 2500°C 3 857 200 3 857 220 3 857 210 3 857 230
IS 5 MB 30: 1000 ... 3000°C 3 857 250 3 857 270 3 857 260 3 857 280
IGA 5 MB 18: 350 ... 1800°C 3 857 400 3 857 420 3 857 410 3 857 430
IGA 5 MB 20: 250 ... 2000°C 3 857 350 3 857 370 3 857 360 3 857 380
IGA 5 MB 25: 400… 2500°C 3 857 450 3 857 470 3 857 460 3 857 480
IGA 5 MB 30: 500 ... 3000°C 3 857 920 3 857 940 3 857 930 3 857 950
IS 5-C; IGA 5-C (with PID controller)
Type Temperature range targeting
light, RS232
view finder,
RS232
targeting
light, RS485
view finder,
RS485
IS 5-C MB 20: 600 ... 2000°C 3 851 150 3 851 170 3 851 160 3 851 180
IS 5-C MB 25: 800 ... 2500°C 3 851 200 3 851 220 3 851 210 3 851 230
IS 5-C MB 30: 1000 ... 3000°C 3 851 250 3 851 270 3 851 260 3 851 280
IGA 5-C MB 18: 350 ... 1800°C 3 851 400 3 851 420 3 851 410 3 851 430
IGA 5-C MB 20: 250 ... 2000°C 3 851 350 3 851 370 3 851 360 3 851 380
IGA 5-C MB 25: 400… 2500°C 3 851 450 3 851 470 3 851 460 3 851 480
IGA 5-C MB 30: 500 ... 3000°C 3 851 920 3 851 940 3 851 930 3 851 950
IS 5-TV; IGA 5-TV (with video module)
Type Temperature range RS232 RS485
IS 5-TV MB 20: 600 ... 2000°C 3 847 150 3 847 160
IS 5-TV MB 25: 800 ... 2500°C 3 847 200 3 847 210
IS 5-TV MB 30: 1000 ... 3000°C 3 847 250 3 847 260
IGA 5-TV MB 18: 350 ... 1800°C 3 847 400 3 847 410
IGA 5-TV MB 20: 250 ... 2000°C 3 847 350 3 847 360
IGA 5-TV MB 25: 400… 2500°C 3 847 450 3 847 460
IGA 5-TV MB 30: 500 ... 3000°C 3 847 920 3 847 930
