Lumens LC200 User Manual

10
No
Item
Function Descriptions
1
Device
Identification
Defines the device name and device description for LC200
※Display name only accepts English characters and numbers
2
Live
Displays the real-time PGM screen
3
Date & Time
LC200 supports different time zone setting. It can synchronize time with NTP
service (default) and manual setup
 Time Zone: Select the correct time zone according to current location
 Configuration Mode:
 NTP service: Synchronize time with a network server
 Manual Setup: Set time manually
4
Front Panel Lock
Select to enable Front Panel Lock
 Even though LC200 is rebooted, it will remain locked.
To disable this function, please log in to the web page to uncheck this item.
5.
Frame Rate
Mode
You can configure the output frame rate at 30/60 fps
※If the frame rate setting of LC200 is 60 fps
 Up to 2 network image inputs are supported
 Recording can only be Movie Mode
 Streaming video compression format is the same as recording
6.
Welcome Image
You can customize a welcome image for LC200
1 Click [Browse] and select a file to upload. Once done, a thumbnail will be
generated
※File format:
 File format: PNG
 File Size (Max.): 3 MB
 Resolution Size (Max.): 1920 x 1080
2 Click [Apply] to save this change. If you need to select another file, click
[Cancel] and reselect a file
7.
Intermission
screen
Users can change the image files
 File format: PNG
 File Size (Max.): 3MB
Resolution Size (Max.): 1920 x 1080
[Remark] You can select different system frame rates in the frame rate mode that affects the
supported recording mode and network streaming number. Please refer to the following
restrictions on use.
System
Frame
Rate
Supported
Recording
Mode
Streaming
Video
Compression
Settings
Network Streaming (IP)
MultiView
signal source
selection limits
PGM Maximum
Split-screen
Quantity
Maximum
number of
streams
supported
Maximum
frame rate
supported
FPS30
Mixed Video /
Original Source
Full HD 30 FPS
HD 30 FPS
SD 30 FPS
3 streams
Full HD 30 FPS
IP + HDMI = 4
channels
IP ≤ 3
(only CH1~3
available for
selection)
4 channels
FPS60
Mixed Video
Full HD 60 FPS
2 streams
Full HD 60 FPS
IP + HDMI = 4
channels
IP ≤ 2
(only CH1~2
available for
selection)
2 channels

Lumens LC200 Specifications

General

Internal	No
Product color	Black
LED indicators	Yes
Number of persons	- person(s)
Supported aspect ratios	16:9
Analog signal format system	-
HDMI in	4
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	1
Headphone outputs	0
USB connector type	USB Type-A
HDMI ports quantity	6
Number of HDMI outputs	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC adapter output current	2 A
AC adapter output voltage	12 V
Maximum frame rate	60 fps
Supported resolutions	640 x 480, 1280 x 720, 1920 x 1080
Supported video modes	480p, 720p, 1080p
Megapixel	- MP

Weight and Dimensions

Depth	122.5 mm
Width	431 mm
Height	44.3 mm
Weight	1200 g
