Lumens LC200 User Manual

30
5.4 File management
LC200 provides file management feature which can perform the following functions
via the file management interface: Upload, download, delete, replay video files and
editing recording information.
No
Item
Function Descriptions
1
Preview Screen
Click desired video files to play and control on the Preview screen
2
Program Screen
Display the Director screen or switch to synchronize with the Preview screen
3
Screen Switch
Button
Switch the Program screen to the LIVE Director screen or the Preview
screen
4
Discovery
You can search recording video files by selecting date period on the calendar
5
Display Mode
Switch
Video view mode. You can switch to thumbnail mode or list mode
6
Folder Display
Display the recording video folders
7
Video File Display
Display the files in the video folder
8
File Management
Delete, backup or copy recording video to an external USB flash drive
2
1
3
4
5
6
7
8

Lumens LC200 Specifications

General

Internal	No
Product color	Black
LED indicators	Yes
Number of persons	- person(s)
Supported aspect ratios	16:9
Analog signal format system	-
HDMI in	4
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	1
Headphone outputs	0
USB connector type	USB Type-A
HDMI ports quantity	6
Number of HDMI outputs	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC adapter output current	2 A
AC adapter output voltage	12 V
Maximum frame rate	60 fps
Supported resolutions	640 x 480, 1280 x 720, 1920 x 1080
Supported video modes	480p, 720p, 1080p
Megapixel	- MP

Weight and Dimensions

Depth	122.5 mm
Width	431 mm
Height	44.3 mm
Weight	1200 g
