Lumens LC200 User Manual

12
5.2.1.3 Services
No
Item
Function Descriptions
1
Main Firmware
Main firmware information and update
Click [Update] and select the main firmware file to update
2
Secondary
Firmware
Secondary firmware information and update
Click [Update] and select the secondary firmware file to update
3
Service History
Saves system log files to user’s computer
1 Enter file name
2 Click [Export] to export system log files
※The length of file name must be between 0 ~ 16 characters.
{}()’&@~^$%”|,`:?<>*\/#; symbols, and space are forbidden
4
Reset
Restores LC200 to factory reset
※Check [Keep Network Settings] and the network settings will be remained
5
Restart the
device
Restart the LC200
1
2
3
4
5

Lumens LC200 Specifications

General

Internal	No
Product color	Black
LED indicators	Yes
Number of persons	- person(s)
Supported aspect ratios	16:9
Analog signal format system	-
HDMI in	4
USB version	3.2 Gen 1 (3.1 Gen 1)
Audio (L/R) out	1
Headphone outputs	0
USB connector type	USB Type-A
HDMI ports quantity	6
Number of HDMI outputs	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
AC adapter output current	2 A
AC adapter output voltage	12 V
Maximum frame rate	60 fps
Supported resolutions	640 x 480, 1280 x 720, 1920 x 1080
Supported video modes	480p, 720p, 1080p
Megapixel	- MP

Weight and Dimensions

Depth	122.5 mm
Width	431 mm
Height	44.3 mm
Weight	1200 g
