Video Conference - Connecting to the conference host
<Remark> Camera System S
witch should be set to HDMI Mode
4.3.4
Connect Multiple VC-B30U Set
s Through VISCA
<Remark> Camera System S
witch should be set to HDMI Mode
<Remark> With RS-232 in/
out, at most 7 VCs can be connecte
d.
Camera
Decoder
A
UDIO Cable
Microphone
Monitor
HDMI Cable
HDMI Cable
VISCA
Cable
Monitor
Camera
HDMI Cable
VISCA
Cable
AUDIO Cable
