Lumens VC-BC701P User Manual

11
Chapter 5 Network Function Settings Description
5.1 Web System Requirements
5.1.1 Web Browser:
 Internet Explorer 11 or above
 FireFox 66.0.3 or above
 Chrome 73 or above
 Edge 42.17134 or above
 Safari 12.1 or above
5.2 Connecting Camera to Network
5.2.1 Connecting to Internet
Two common connection methods are shown below
1. Connecting via switch or router
2. If the camera is connected to the computer directly, the computer IP address must be modified to
have the same network segment as the camera
For example, the factory-preset default IP address of VC-BC701P is 192.168.100.100. The computer
IP address must be set with the same subnet, such as 192.168.100.101, so that the computer can be
connected correctly with the camera
 Connection diagram
Switch or router
Ethernet cable
Ethernet cable
VC-BC701P Computer
Ethernet cable
VC-BC701P Computer
