The LumiNode 1 can be powered with a USB cable or with PoE . The device will automatically witch
on. To shut it down after use, just un-plug the USB cable or the network cable again.
The LumiNode series are 802.3af compliant (PoE), so that each LumiNode will act as a PD (Powered Device)
and can be powered by any compliant PSE (Power Sourcing Equipment) such as Ethernet switch, midspan
and PoE injector. All models can only be powered with PoE via ETH2!
To get the LumiNode 1 online in your system, connect either the ETH or USB port to a computer, or to a
port of an Ethernet switch.
The LumiNode 1 can be powered through its USB port. Connect the LumiNode 1 to the USB port of your
computer.
The red LED next to the USB port of your device will turn on once the unit is powered. When the unit has
booted up the LED will turn blue.
Additionally, the LumiNode 1 will appear as a new network interface on your computer. No driver is
needed. The LumiNode 1 supports Windows, Mac OSX and Linux OS. Once the network adaptor has been
added please congure a static IP address in the range you are planning to use for your application in the
settings of your operating system.
