ENGLISH
CONTENTS
Technical data .............................................................................10
Guarantee ...................................................................................10
Instructions .................................................................................. 10
Safety Regulations ......................................................................10
General Safety Rules ..................................................................10
Installation .................................................................................11
Use ..............................................................................................11
Maintenance ................................................................................11
Cleaning ......................................................................................11
Installation ...................................................................................11
Lubrication ................................................................................. 11
Connections to Mains .................................................................11
Spindle Speed Selection ............................................................11
General ........................................................................................11
Drive Gear Box .......................................................................... 11
Spindle ........................................................................................11
Counter Balancing the Spindle ...................................................11
Motor...........................................................................................11
Electric diagram ..........................................................................12
Spare Parts List ..........................................................................34
EU Declaration of conformity ....................................................40
GUARANTEE
• This machine is guaranteed by us for one year, counted from
date of invoice. Should during the guarantee period any part of
themachinebeproveddefectiveinmaterialworkmanship,we
guarantee at our own discretion to supply free of charge a new
parttorepairthedefectivepart,providedthatitisreturnedtoour
factory freight prepaid.
• Thepurchaser/agentshallnotifyusinwritingwithoutdelay,of
any defects that have appeared and shall give us every opportu-
nity of inspecting and remedying them.
• The purchaser / agent will not effect repair on-site, without
first having consulted us. Should such repair on-site be effected
without previous acceptance from us, this will be done at the
purchasers or agents own risk and expense.
• Weassumenoliabilityfordefectsinthemachineduetoextra-
neous circumstances, wear, lack of due care and attention or
faultyhandling,norcanweacceptanyobligationwhatsoeverto
provide compensation for other direct or indirect costs in con-
nection with cases covered by this guarantee.
INSTruCTIONS
This is your copy of the instructions and spare parts list for the
drilling machine. It has been prepared for those using the machine
or who are responsible for its maintenance and service and should
therefore be made readily available for all those concerned. Read
through the manual carefully before installing and starting up.
Themachineisofsimpledesignandrobustlybuilt,butwecannot
guarantee perfect function if it is incorrectly handled. It is there-
fore necessary to make yourself thoroughly acquainted with the
function and to carry out practical tests on the various parts in the
control system and the machine settings. Once these are mastered
the excellent properties of the machine can be fully utilized and the
component parts will give maximum service life. Every machine is
tested for accuracy and capacity at the factory. Experienced staff
checks both the mechanical and electrical functions according to a
standardizedprogram,meaningthatwecanguaranteeworkman-
ship of the highest and most consistent quality. By following our
directions and your own good judgment we are convinced that you
will be satisfied with your new machine. However, should any
problemsarise,pleasedonothesitatetocontactourdealerorus.
SafETy rEGuLaTIONS
of the best concerning design and safety. However, any mach-
ine which is used incorrectly can be a safety risk. It is of vital
importance,thatthosewhousethemachineareinformedhowto
handle it correctly. They should read and understand these instruc-
tions as well as all plates available on the machine. Ignoring to
follow the safety regulations might cause an accident.
Warning!
•Usingthemachineincorrectlycancauseseriousaccidents.
•Themachinehastobeinstalled,usedandmaintainedcorrectly.
GENERAL SAFETY RULES
All machines with rotating tools or details can cause accidents. It is
therefore important that you as an operator are aware of those risks
for any accident and that you avoid all possibilities for accidents.
•Alwaysusesuitableclothesandpersonalequipment,sothatyou
cannot get caught by rotating tools.
•Alwaysuseprotectivegogglesifthereexistsariskforchipsor
splashes from the coolant. Follow local instructions if existing.
•Keep it clean around the machine to avoid stumbling against
rotating tools.
•See to it, that the work piece is securely fastened at the table.
Never use your hand to hold the work piece.
•Seetoit,thattheswitchisinthe0positionwhenchangingtools
or when cleaning the machine.
•Neverbrushawaychipswhilethemachineisoperating.
•Usefaultlesstoolsandthecorrectspeedandfeedforthetool.Be
sure that the tool is the correct one for your operation.
•Seetoit,thatthedrillheadandthetablearethoroughlydamped
before starting up the machine.
•The drill guard that we havefitted to the machinemust not be
removed. In case of removal the existing CE norm becomes
invalid.
TECHNICaL daTa
Art. no ...................................... 20714 -0104 -0203
Luna ............................................... Nr MD30B MD30F
Model ................................................. Bench Upright
Design ................................................ Manual Manual
Drill capacity in steel ................... mm 25 25
Tapping capacity
(max.4times/min) .......................... M 16 16
Spindle taper ................................ MT 3 3
Spindle movement ....................... mm 130 130
Spindle speed .................................ea. 8 8
Spindle speed 50Hz .....................rpm 105-2900 105-2900
Spindle speed 60Hz .....................rpm 126-3480 126-3480
Column diameter .......................... mm 100 100
Distance spindle centre - column mm 255 255
Max./min.distance
spindle nose - bench .................... mm - 915/0
Spindle nose-foot plate ................... V 584/80 -
Table size ..................................... mm - 500x350
Table pin Ø .................................. mm 60 60
T-slot width .................................. mm 14 14
T-slotc/c ...................................... mm 140 140
Sound level .............................dB(A) 76 76
Motor voltage .................................. V 400+/-10%3-fas 400+/-10%3-fas
..................................................................... 50-60Hz 50-60Hz
Workingplan,machinedfoot ...... mm 14 -
Motor output .................................kW 0.65/0.9 0,65/0,9
Rated current ................................... A 1,8/2,3 1,8/2,3
Weight ............................................ kg 130 170
