A-4
CDA3000 Operation Manual
CDA34.072,Wx.x 37
4
8
72
72
72
62
112
78
112
112
CDA34.090,Wx.x 45
4
8
90
90
90
78
135
104
135
135
CDA34.110,Wx.x 55
4
8
110
110
110
96
165
110
165
165
CDA34.143,Wx.x 75
4
8
143
143
143
124
215
143
215
215
CDA34.170,Wx.x 90
4
8
170
170
170
147
255
212
255
255
CDA34.250,Wx.x 132 4 250 250 255 300
Peak current for 30 s with inverter module 0.75 to 15 kW
Peak current for 60 s with inverter module 22 to 132 kW
Cooling air temperature: 45 °C at power stage switching frequency 4 kHz
(CDA34.003 - 34.032) 40 °C at power stage switching frequency 8, 16 kHz
Cooling air temperature:40 °C at power stage switching frequency 4 kHz
(CDA34.045 - 34.250)
1) With heat sink HS3... or additional cooling surface
2) Mains voltage 3 x 400 V ±10 %
3) Mains voltage 3 x 460 V ±10 %
Motor cable length 10 m
Mounting height 1000 m above MSL
End-to-end mounting
Inverter module
Rec. 4-pole
standard motor
[kW]
Switching
frequency of
power stage
[kHz]
Rated
current I
N
[A]
at 400V
2)
Rated
current
I
N
[A]
at 460V
3)
Peak current for
intermittent
mode
0 to 5 Hz [A]
Peak current for
intermittent
mode
> 5 Hz [A]
