Lust CDA32.006 - Page 62

A-6
CDA3000 Operation Manual
CDA34.008 to CDA34.060
Designation
Technical data
CDA34.008 CDA34.010 CDA34.014 CDA34.017 CDA34.024 CDA34.032 CDA34.045 CDA34.060
Output, motor side
Recommended rated power
with 4-pole Standard motor
3.0 kW 4.0 kW 5.5 kW 7.5 kW 11 kW 15 kW 22 kW 30 kW
Voltage 3 x 0 ... 400/460 V
Continuous current (RMS) (I
N
)
7.8 A 10 A 14 A 17 A 24 A 32 A 45 A 60 A
Peak current 1.8 x I
N
for 30 s
14 A 18 A 25 A 31 A 43 A 58 A 68 A 90 A
Rotating field frequency 0 ... 400 Hz 0 ... 200 Hz
Switching frequency of power stage 4, 8, 16 kHz 4, 8 kHz
Input, mains side
Mains voltage 3 x 460 V -25 % +10 %
Device connected load 5.7 kVA 7.3 kVA 10.2 kVA 12.4 kVA 17.5 kVA 23,3 kVA
32.8
kVA
43.8 kVA
Asymmetry ±3 % max.
Frequency 50/60 Hz ±10 %
Power loss at Power stage4 kHz
clock frequency 8/16 kHz
135 W
162 W
172 W
207 W
210 W
268 W
255 W
325 W
315 W
400 W
400 W
510 W
777 W
933 W
1010 W
1220 W
Braking chopper power electronics
Peak braking power with int.
braking resistor (only with version
CDA34 ..., Wx.x, BR)
6.0 kW
at 90
Ω
6.0 kW
at 90
Ω
6.0 kW
at 90
Ω
-
Minimum ohmic resistance of an
externally installed braking resistor
81 Ω 47 Ω 22 Ω 18 Ω
