A.2 Technical data
CDA32.004 to CDA34.006
Designation
Technical data
CDA32.004
CDA32.006 CDA32.008
CDA34.003
CDA34.005 CDA34.006
Output, motor side
Recommended rated power
with 4-pole Standard motor
0.75 kW 1.1 kW 1.5 kW 0.75 kW 1.5 kW 2.2 kW
Voltage 3 x 0 ... 230 V 3 x 0 ... 400/460 V
Continuous current (RMS) (I
N
)
4.0 A 5.5 A 7.1 A 2.2 A 4.1 A 5.7 A
Peak current 1.8 x I
N
for 30 s
7.2 A 9.9 A 12.8 A 4.0 A 7.4 A 10.3 A
Rotating field frequency 0 ... 400 Hz
Switching frequency of power stage 4, 8, 16 kHz
Input, mains side
Mains voltage
1 x 230 V
-20 % +15 %
3 x 460 V
-25 % +10 %
Device connected load 1.7 kVA 2.3 kVA 3.0 kVA 1.6 kVA 3.0 kVA 4.2 kVA
Asymmetry of mains voltage - ±3 % max.
Frequency 50/60 Hz ±10 % 50/60 Hz ±10 %
Power loss at 4 kHz
Power stage clock
frequency 8/16 kHz
48 W
55 W
75 W
82 W
95 W
105 W
55 W
70 W
80 W
112 W
106 W
148 W
Braking chopper power electronics
Peak braking power with int.
braking resistor (only with version
CDA34 ..., Wx.x, BR)
- - – –
1.6 kW
at 360
Ω
Minimum ohmic resistance of an
externally installed braking resistor
100 Ω 56 Ω 180 Ω
