Luster HME5000-C2-E2-PU-I2-0 - Technical Data

Installation Instructions DualGig-2.5 20200506 22
Technical data*)
Basic information Technical standard MoCA 2.5
Network nodes 16 max. in 1 network
Communication Modulation OFDMA
Sub-carrier number 512
Sub-bandwidth BPSK, QPSK, 8QAM, 16QAM,
32QAM, 64QAM, 128QAM,
256QAM, 512QAM, 1024QAM
MAC layer protocol TDMA/TDD
RF RF band / Channel width 1125-1675 MHz / 100 MHz
D-band extended 1125-1675 MHz
D-band low 1125-1225 MHz
D-band high 1350-1675 MHz
E-band
1)
400-700 MHz
F-band
2)
650-875 MHz
Channel width 100 MHz
Up/down in the RF-band bundled, 100 MHz band width
Standard channel default 1350-1450 MHz
Channel default 1125-1225 MHz
Max output power + 3dBm (+2 dBm typical)
Input sensitivity - 70 dBm
Attenuation TV MOCA-IN/OUT < 2 dB
MOCA 5-1675 MHz
IN-OUT 5-1002 MHz
Throughput 2500 Mbps
PHY dataspeed, max 3500 Mbps
Latency 5 msec max. (typical 3 msec)
Interface RF interface F-female, 75 ohm
Data interface 2xRJ45, 1000Base-Tx Ethernet
Power supply DC 5Volt/1 Amp via MiniUSB
Power absorption < 5 Watt
Dimensions 129*80*32 mm (LxBxH)
Weight < 1 kg
Temperature -10 - +45
o
C
Huminidity 5% - 90% without condensation
* Specications according to manufacturer’s specications, no rights can be derived from this
1)
Not adjustable in Europe
2)
Not adjustable in Europe
