50
General technical specifications
Transmitter
Frequency range 144 - 146 MHz / 430 - 440 MHz
Frequency stability ± 2.5 ppm
Operating voltage 7.2 Vcc (rechargeable Li-Ion battery)
Memory channels 2 x 128
Antenna High gain
Antenna impedance 50Ω
Operation mode Simplex or semi-duplex
Battery capacity 3600 mA
Power output ≤ 10W VHF / ≤ 9W UHF / 5W (low power)
Modulation mode 16K*F3E / 11K*F3E
Maximum deviation ≤ 5 KHZ, ≤ 2.5KHz
Spurious radiation emitted ≤ 7.5µW
Adjacent channel power ≤ -65dB / ≤ -60dB
Pre-emphasis characteristics 6 dB
Current ≤ 2.8 A (10W) ≤ 1.8 A (5W)
Intermediation sensitivity 8 - 12 mV
Audio distortion < 5 %
ATTENTION: Some of these specifications can be subject to modification without previous notice.
