5. MEASURING PROCEDURE
5-1 Symbols & units of display
Symbols Descriptions
Units
AUTO Appears when selecting " Automatic range " mode.
Appears when selecting DC mode.
( DC voltage or DC current )
Appears when selecting AC mode.
( AC voltage or AC current )
HOLD Appears when the " Data hold " function is operated.
REL Appears when the " Relative " function is operated.
Battery voltage is already under the low condition.
Appears when the " Continuity beeper " is operated.
mV, V Units for voltage measurements.
uA,mA,A Units for " Current " measurement.
Ω ,KΩ ,MΩ Units for resistance measurements.
nF,uF Units for " Capacitance " measurement.
Hz,KHz,MHz Units for " Frequency " measurement.
% Duty
Appears when the " Diode " function is operated.
－ Appears when measuring a DCV or DCA value
is negative.
OL Over range indicator
9
