4)When LCD show the " AUTO " marker, the meter is
under the " auto range " mode. Meter will select the
suitable measurement range automatically.
* Under the operation of " auto range " mode, push the
" Range button " ( 3-6, Fig. 1 ) once will execute the
" Manual Range " mode and hold the range, the " AUTO "
marker will be disappeared.
* Under the manual range operation, push the " Range
button " ( 3-6 Fig. 1 ) > 2 seconds, will return to auto
range operation, the " AUTO " marker will present on
the LCD again.
5-4 DC Current, AC Current Measurement
mA : 400 mA range, 40 mA range.
uA : 4000 uA range, 400 uA range.
1)Connect BLACK test lead into " COM " terminal ( 3-11,
Fig. 1 ).
2)For the " mA, uA " measurement, connect RED
test lead into " mA uA " terminal ( 3-10, Fig. 1 ).
For the " 10 A " current measurement, connect RED
test lead into " A " terminal ( 3-9, Fig. 1 ).
Open the circuit in which current is to b
measured. Now securely connect test leads i
series with the load in which the current is b
measured.
11
