Lutron Electronics LOS-CDT Series User Manual

®
SPECIFICATION SUBMITTAL Page
Job Name:
Job Number:
Model Numbers:
Sensors LOS-CDT Series Occupancy Sensors
369653c 8 02.07.13
ON
ON
A
1
2
3
4
B
1
2
3
4
Black:
Timer
8 min
Blue:
Photo cell
(R models only)
100% default
Red:
Infrared
sensitivity
75% default
Green:
Ultrasonic
range
50% default
Off (Default) On
Automatic (Normal) Manual on / off (Override)
Auto Threshold Adjustment High Sensitivity (Low turn-on threshold)
Lights indicate motion Disable LED Indicator
Retain Settings (Normal) Erase all learned settings; Restart Learning (Toggle On)
Sensor Adjustments
Timer Test Mode
Factory Settings
1. Remove the retainer cover.
2. Rotate the black timer adjustment knob to about
midway (12 o’clock).
3. Return setting to minimum setting (full CCW).
NOTE: The timer will remain in the 8 second test mode
for 1 hour, then automatically reset to 8minutes.
4. To manually take the timer out of the 8 second test
mode, turn the timer adjustment approximately 1/16in
(1.5 mm) clockwise to make the setting slightly above
minimum (just above the 8 minute setting).
Factory Settings 12 o’clock
Full CCW
Auto/Manual
Threshold
LED Motion Indicator
Reset Learned Settings
Strong Airflow Compensation
Over Doorway Installation
Timer Adjust
Auto Sensitivity
ONOFF
ONOFF
ONOFF
ONOFF
A
1
2
3
4
B
1
2
3
4
Override Settings
Off (Default) On
Disable Compensation (Normal) Enable Compensation
No (Normal) Yes (Use increased turn-on threshold)
Adjust Timer Automatically Use Manual Setting (No adjustment)
Adjust Sensitivity Automatically Adjust Sensitivity Manually
Continued on next page...
