6. CALIBRATION
* The sound level meter is built in the internal
" External calibration VR " ( 3-5, Fig. 1 ) on the front
panel.
* Please according the following procedures to calibrate
the instrument accurately, if it is necessary.
1) Prepare the optional " SOUND CALIBRATOR, model:
SC-941, SC-942 or other equivalent sound calibrator.
Power on the Sound Calibrator & plug calibrator output
into the " Electric condenser micro- phone " ( 3-1, Fig. 1 )
of the Sound Level Meter.
2) Slide the " Range switch " ( 3-4, Fig. 1 ) to " 50 - 100 dB "
position.
3) Carefully adjust the " Calibration VR " ( 3-5 ) with " - "
screw driver, until the display read within " 94.0 ± 0.2 " dB.
5
