RS232 FORMAT : 9600, N, 8, 1
Baud rate 9600
Parity No parity
Data bit no. 8 Data bits
Stop bit 1 Stop bit
12. Optional Type K Temp. probe
(Type K) TP-01 * Max. short-tern operating
Temperature: 300 (572 ).℃℉
* It is an ultra fast response
naked-bead thermocouple
suitable for many general purpose
application.
Thermocouple * Measure Range: -50 to 900 ,℃℃
Probe -58 to 1650 .℉℉
(Type K), TP-02A * Dimension:12cm tube, 3.2mm Dia.
Thermocouple * Measure Range: -50 to 1100 ,℃℃
Probe -58 to 2012 .℉℉
(Type K), TP-03 * Dimension: 13.6cm tube, 8mm Dia.
Surface Probe * Measure Range: -50 to 400 ,℃℃
(Type K), TP-04 -58 to 752 .℉℉
* Size :
Temp. sensing head - 15 mm Dia.
Probe length - 120 mm.
24
