3. FRONT PANEL DESCRIPTION
Fig. 1
3-1 Display
3-2 Power Button ( ESC, Backlight Button )
3-3 Hold Button ( Function, Next Button )
3-4 REC Button ( Enter Button )
3-5 SET Button ( Button, Time check Button )▼
3-6 Logger Button ( Button, Sampling time check Button, Zero Button )▲
3-7 Probe input socket
3-8 Type K/J Temp. Probe Input Socket
3-9 SD card socket
3-10 RS-232 Output Terminal
3-11 Reset Button
3-12 DC 9V Power Adapter Input Socket
3-13 Battery Compartment/Cover
3-14 Battery Cover Screws
3-15 Stand
3-16 Tripod Fix Nut
3-17 UVC Probe Plug
3-18 UVC Sensor body
3-19 UVC Sensor
