* SD card capacity : 1 GB to 16 GB.
* LCD with green light backlight, easy reading.
* Can default auto power off or manual power off.
* Data hold, record max. and min. reading.
* Microcomputer circuit, high accuracy.
* Power by UM3/AA ( 1.5 V ) x 6 batteries or DC 9V
adapter.
* RS232/USB PC computer interface.
2. SPECIFICATIONS
2-1 General Specifications
Circuit Custom one-chip of microprocessor LSI
circuit.
Display LCD size : 52 mm x 38 mm
LCD with green backlight ( ON/OFF ).
Measurement UVC Light
Type K/J thermometer
UVC Sensor 220 nm to 280 nm.
spectrum
UVC light sensor spectrum, refer to
cover range
page 5.
UVC sensor The exclusive UV photo sensor with
structure the cosine correction filter.
UV light zero By push button.
adjustment
Memory with Records Maximum & Minimum reading
Recall with recall.
2
