Power Supply *
A
Alkaline or heavy duty DC 1.5 V battery
( UM3, AA ) x 6 PCs, or equivalent.
*
A
DC 9V adapter input. ( AC/DC power
adapter is optional ).
Power Current Normal operation ( w/o SD card save
data and LCD Backlight is OFF) :
Approx. DC 6.5 mA.
When SD card save the data but and
LCD Backlight is OFF) :
Approx. DC 30 mA.
*
A
If LCD backlight on, the power
consumption will increase approx.
16 mA.
Weight Meter 351 g
UVC probe 103 g
Dimension Meter 177 x 68 x 45 mm
UVC probe 38 mm DIA. x 25 mm
Accessories * Instruction manual....................... 1 PC
Included * UVC light sensor...........................1 PC
* Hard carrying case, CA-06............
.
1 PC
Optional SD Card ( 2 GB )
Accessories Type K thermocouple probe.
AC to DC 9V adapter.
USB cable, USB-01.
RS232 cable, UPCB-02.
Data Acquisition software,SW-U801-WIN.
2-2 Electrical Specifications (23±5 )℃
UVC Light range/resolution/accuracy
Measurement Range 1 : 2 mW/cm^2 :
ranges &
1.999 mW/cm^2 x 0.001 mW/cm^2
resolution Range 2 : 20 mW/cm^2 :
Accuracy ± ( 4 % FS + 2 dgt ). FS : full scale
* UVC Calibration is executed under the UVC light &
and compare with the standard UVC light meter.
4
