Lutz MD2xL User Manual

12
en
0698-401 MD1xL / MD2xL - 08/2020
5. Operation
!
WARNING
Danger of rolling-up and pulling-in of objects!
► Do not put any objects in the opening for the coupling control
(→Fig.4).
►Donotworkonthemotorwiththinandloose-ttinggloves.
!
WARNING
Danger of injury due to uncontrolled restarting of the motor!
► The pump must not be left unattended while in operation.
►Ifthepowersupplyfails,themotormustbeswitchedo.
5.1 Controlling compressed air motor MD1xL
►Forswitching-on/othemotor,insertacheckvalveinthecom-
pressedairline(e.g.ballvalvefromLutzaccessories).
5.2 Controlling compressed air MD2xL
► On: Moveswitchfromtheo-position(→Fig.5,item1)tothe
required speed (→Fig.5,item2).
O: TurnbacktheswitchtoO-position.
Fig. 4
Fig. 5
