BURNER MAINTENANCE & CLEANING
ATTENTION
SPIDERS & INSECTS:
REASSEMBLE THE BURNERS:
If the burners are not centered firmly and correctly, a dangerous condition may
occur that can cause personal injury and damage to your gas grill.
Sometimes spiders and insects may crawl inside burners and nest there. In this case, the gas
will flow from the front of the burner. It can create a dangerous situation and start a fire behind the
valve panel. This can damage the grill and make the operation of it unsafe..
When replacing the burner, align the
orifice with the center hole on Infra red burner.
Slide the burner onto the orifice and rest the
rear of the burner (the U shaped end) on the
support rack at the back of the burner box.
Make sure the burner is resting firmly and
does not rock. Light all burners and check
the flames for irregularities.
Burner Maintenance And Cleaning (continued)
INFRA RED BURNER
GRILL BURNERS:
Make sure grills are not hot. Begin by removing the cooking grills off the gas grill, Grab the burner
from the sides and gently lift the part resting on the burner bracket. Slide burner up and back
gently making sure you do not brake the electrode.
Brush of the metal screen. If necessary a vacuum can be used to lift debris out of the ceramic ports.
IT IS JUST AS IMPORTANT TO CLEAN INSIDE THE GAS INTAKE PIPE (VENTURI) by a small and long brush. You
should use a flashlight to make sure it is clean and there are no restrictions in the burner or the venturi.
BURNER CLEANING:
ORIFICE CLEANING:
After the burner has been removed, remove the orifice and hold a flashlight through the opening
to check for possible blockage. Use a needle to clean any debris. use extreme caution so you
do not enlarge the hole or break off the needle.
Air inlet
Air shutter
VALVE
CERAMIC BURNER
PAGE 14
