GAS CONNECTION
L.P. Cylinder (tank) requirements:
The LP Tank / gas cylinder for your grill is not provided from by our factory. Therefore, make sure that
only D.O.T. approved 20 Lb., or CAN/CGA-B339 approved L.P. gas tanks are used with the grill. All
approved Cylinders must have an integral collar designed to provide protection around the
cylinder valve and prevent damage. Do not use a damaged gas cylinder. Do not attempt to
repair a damaged tank at anytime. A dented or rusty L.P. tank may be hazardous and should be
checked by your L.P. supplier. Never use a cylinder with a damaged valve. Always
check for leaks after every L.P. tank change.
Gas Connection (continued)
Additional tips for safety:
If the assembly needs to be replaced, use a unit specified by LUXOR Grills only. Then:
1. Remove the panel in the back of the BBQ to reach the regulator and gas connection area.
2. Route the female end of the hose through the cart
3. Fasten the hose connection to 1/2" x 3/8" flare fitting connected to the Grill Regulator
When connecting the L.P. gas tank, make sure the hose does not come in contact with the grill
or a hot surface. For the use with an L.P. tank / cylinder, the LUXOR grill is equipped with its own
regulator. DO NOT REMOVE THIS REGULATOR.
A proper regulator should always be used with any gas operation. Check with the local Gas
Codes for proper installation. You must use a regulator approved by A.H. T. for any application.
L.P. Gas Connection:
NEVER CONNECT THE GRILL TO AN UNREGULATED GAS SUPPLY
Manifold pressure: (operating) 10.5" W.C.
The L.P. gas cylinder must be constructed and marked in accordance with the specifications for
the L.P. gas cylinder of the U.S. Department of Transportation (DOT) and designed for use with a
QCC or type 1 system. The gas cylinder must be provided with a shut off valve terminating in an L.P.
gas supply cylinder valve outlet specified, as applicable, for connection type QCC1 in the standard
for compressed gas cylinder valve outlet and inlet connection ANSI/CGA-V-l.:
- Extra or spare gas tanks must be stored at least 15 feet fam the grill or any open flame, or
other types of heat producing device or source.
- Gas tanks are equipped with a pressure relief valve. In case a tank is exposed to excessive heat,
the relief valve lets the highly flammable gas vapor or liquid escape. That is why you should never
store the gast tank near heat or a flame.
- Store the gast tank in a well ventilated area
- Do not fill your gas cylinder beyond 3/4 full
PAGE 8
