Information about Installation:
• There is a requirement that all work be performed by a qualified service
professional and in accordance with all national, state, and local regula-
tions.
• Ensure that electrical components are properly drained in the compart-
ment.
• There are several models of pump included in these instructions, so
some may not apply to a specific model. All models are geared toward
swimming pool use. If the pump is properly sized for the specific applica-
tion and properly installed, it will function correctly.
IMPORTANT WARNING AND SAFETY INSTRUCTIONS
A high level of suction can be generated by the
pump in the plumbing system's suction side. The high
level of suction can pose a threat to those in close proximity to the suction
openings. This high vacuum can cause serious injuries or cause people to
become trapped and drown. Swimming pool suction plumbing must be
installed according to the latest national and local codes.
A clearly identified emergency shut-off switch for the
pump should be located in a highly visible location.
Ensure that all users know where it is located and how to use it in case of
an emergency.
The Virginia Graeme Baker (VGB) Pool and Spa Safety Act establishes
new requirements for commercial swimming pool and spas owners and
operators.
On or after December 19, 2008, commercial pools and spas must use:
A multiple main drain system without isolation capability with suction outlet
covers complying with ASME/ANSI A112.19.8a Suction Fittings for
Swimming Pools, Wading Pools, Spas, and Hot Tubs and either:
(1) Safety vacuum release systems (SVRS) that meet ASME/ANSI
A112.19.17 Manufactured Safety Vacuum Release systems (SVRS) for
Residential and Commercial Swimming Pools, Spas, Hot Tubs, and
Wading Pool Suction Systems, or ASTM F2387 Standard Specification for
Manufactured Safety Vacuum Release Systems (SVRS) for Swimming
Pools, Spas and Hot Tubs
(2) Suction-limiting vents that have been properly designed and tested
(3) System for shutting off pumps automatically
Pools and spas constructed before December 19, 2008, with a single
submerged suction outlet, must use a suction outlet cover that meets
ASME/ANSI A112.19.8a or either:
(A) A SVRS compatible to ASME/ANSI A112.19.17 and/or ASTM F2387,or
(B) Suction-limiting vents that have been properly designed and tested or
(C) System for shutting off pumps automatically, or
(D) Submerged outlets can be disabled or
(E) Reconfiguration of suction outlets into return inlets is required.
WARNING
WARNING
The improper size, installation, or use of pumps in
applications for which they were not designed can
result in serious personal injury or death. There are a number of risks
involved, including electric shocks, fires, flooding, suction entrapment,
severe injury to others or property damage as a result of structural failures
in pumps or other system components.
Pumps and replacement motors that are single speed and one (1) Total HP
or greater cannot be sold, offered for sale, or installed in a residential pool
for filtration use in California, Title 20 CCR sections 1601-1609.
WARNING
Installing electrical controls at the equipment pad
(ON/OFF switches, timers, and automation load
centers)
Ensure that all electrical controls are installed at the equipment pad,
including switches, timers, and control systems. To prevent the user from
putting his/her body over or near a pump strainer lid, filter lid, or valve
closure when starting, shutting down, or servicing a pump or filter.
During system start-up, shutdown, or servicing of the filter, the user should
be able to stand far enough away from the filter and pump.
CAUTION
When starting up, keep the filter and pump away
from your body.
When parts of a circulating system are serviced (i.e. locking rings, pumps,
filters, valves, etc.) air can enter and pressurize the system. It is possible
for the pump housing cover, filter lid, and valves to violently separate when
subjected to pressurized air. You must secure the strainer cover and filter
tank lid to prevent violent separation.
When turning on or starting up the pump, keep all circulation equipment
clear of you. You should note the filter pressure before servicing the
equipment. Make sure that the pump controls are set so that it cannot start
inadvertently during service.
IMPORTANT: Ensure that the filter manual air relief valve is in the open
position and wait for all pressure in the system to be released.
Open the manual air relief valve fully and put all system valves in the
"open" position before starting the system. Make sure you stand clear of
any equipment when starting the system.
IMPORTANT: If the filter pressure gauge is higher than the pre-service
condition, don't close the manual air relief valve until all pressure has been
released from the valve and a steady stream of water appears.
DANGER
SHP130-VS, SFP220-VS, SWP390-VS Variable Speed Pumps Instruction
For more details and video, please visit www.lingxiao.com.cn
-2-
