SECTION 2 LYCOMING OPERATORS MANUAL
SPECIFICATIONS O-360 AND ASSOCIATED MODELS
DETAIL WEIGHTS (CONT.)
Model Lbs.
O-360 Series
-C4P* .....................................................................................................................................275
-D2A ......................................................................................................................................282
-B2A, -B2C ............................................................................................................................284
-C1E, -C2E.............................................................................................................................285
-A1AD, -A3AD, -C1F, -C2D ................................................................................................288
-A1C, -A1D, -A2D, -A3D, -C2B, -C2C, -J2A ......................................................................289
-A1A, -A2A, -A3A, -A1LD, -C1A, -C2A.............................................................................290
-A2F .......................................................................................................................................291
-A1P, -C1G ............................................................................................................................292
-A1G, -A2G ...........................................................................................................................293
-A1H ......................................................................................................................................294
-A4M, -A4P, -A1F6D, -C4F..................................................................................................295
-A4K, -A4N, -A5AD .............................................................................................................296
-A4D, -A1G6D ......................................................................................................................297
-A4A, -A1F6, -A1H6.............................................................................................................298
-A4J, -A1G6, -F1A6 ..............................................................................................................300
-A4G ......................................................................................................................................301
-G1A6 ....................................................................................................................................303
* - Weight does not include alternator.
HO-360 Series
-A1A ......................................................................................................................................285
-B1A, -B1B, -C1A .................................................................................................................288
IO-360 Series
-L2A.......................................................................................................................................278
-B1C.......................................................................................................................................289
-B1A.......................................................................................................................................295
-B1E .......................................................................................................................................296
-B1D.......................................................................................................................................297
-B1B.......................................................................................................................................299
, -M1B..................................................................................................................................300
-B1F, -B2F .............................................................................................................................301
-B1G6.....................................................................................................................................305
-B4A.......................................................................................................................................307
-B2F6 .....................................................................................................................................308
-K2A ......................................................................................................................................311
-A1D6D, -A3D6D, -C1A.......................................................................................................319
-C1B.......................................................................................................................................320
-C1C, -D1A............................................................................................................................322
-J1AD.....................................................................................................................................323
- For information pertaining to engine model (L)IO-360-M1A, refer to Operation and
Installation Manual P/N 60297-36.
2-8 Revised March 2009

Lycoming IO-360 Series Specifications

General

Oil System	Wet Sump
Engine Type	Horizontally Opposed, 4-Cylinder, Air Cooled
Displacement	361 cubic inches (5.9 liters)
Bore	5.125 in (130.2 mm)
Stroke	4.375 inches (111.1 mm)
Cooling System	Air Cooled
