28
• A pressure regulator must be installed on all gas equipment. All local codes require that
a pressure regulator be installed. Removing or failing to install the pressure regulator can
result in fire and serious bodily harm.
• An installer supplied gas shut-off valve must be installed in an easily accessible location for
all hard-plumbed natural gas and liquid propane applications.
• In order for a Lynx Grill to perform properly you must have adequate gas plumbing. Please
see the guidelines below to help ensure that you have the appropriate gas plumbing with
respect to gas pipe diameter, length of pipe run and the grills BTU requirements.
Internal Pipe
Diameter 10 ft. 20 ft. 30 ft. 40 ft. 50 ft. 60 ft. 70 ft. 80 ft.
1/2” 170,000 BTU 118,000 BTU 95,000 BTU 80,000 BTU 71,000 BTU 64,000 BTU 60,000 BTU 55,000 BTU
3/4” 360,000 BTU 245,000 BTU 198,000 BTU 169,000 BTU 150,000 BTU 135,000 BTU 123,000 BTU 115,000 BTU
Lynx Grill BTU Requirements
Grill Model Main Burners Rotisserie Burners Total
L27 50,000 BTU 15,000 BTU 65,000 BTU
L30 50,000 BTU 15,000 BTU 65,000 BTU
L36 75,000 BTU 15,000 BTU 90,000 BTU
L42 75,000 BTU 16,000 BTU 91,000 BTU
L54 100,000 BTU 30,000 BTU 130,000 BTU
Water Column Requirements
Natural Gas Supply pressure = 7” water column (17.8 cm) min. and
pressure under full load = 4” water column (10.2 cm) minimum.
Liquid Propane Supply Pressure = 11-14” water column (27.9 – 35.5 cm), not to exceed 14” water column and
pressure = 11” water column (27.0 cm) minimum.
Note: All BTU and water column requirements are approximations.
Gas Plumbing Requirements
