M-Audio Fast Track Ultra User Manual

User Guide 9Fast Track Ultra
Monitor Tabs
The four Monitor tabs are similar in layout and in operation. Each will allow you to monitor and control the routing of
the eight hardware inputs, along with eight returns from your DAW, and send those signals to the tab’s corresponding
output pair.
The Monitor tabs’ outputs correspond to Fast Track Ultra’s hardware outputs. Monitor outputs 1/2, 3/4, and 5/6
correspond to the six analog outputs
16
. Monitor outputs 7/8 correspond to the S/PDIF digital output
21
.

M-Audio Fast Track Ultra Specifications

General

Audio Interface Type	USB
Number of Mic Preamps	4
Analog Inputs	8
Analog Outputs	8
Digital Inputs	S/PDIF
Digital Outputs	S/PDIF
Phantom Power	Yes
Headphone Outputs	2
Sample Rate	96 kHz
Bit Depth	24-bit
Compatibility	Windows, macOS
MIDI I/O	Yes
