User Guide 17Fast Track Ultra
11 Specifications
Line Outputs
Frequency Response: 20 Hz to 22 kHz, +/- 0.1 dB @ 48 kHz sample rate
SNR and Dynamic Range: -104 dB, A-weighted
THD+N: 0.002%@ -1dBFS, 1kHz
Signal Level: +10 dBu balanced
+2 dBV, unbalanced
Impedance: 300 Ohm balanced
150 Ohm unbalanced
Crosstalk:
< -100 dB @ 1 kHz
Line Inputs
Frequency response: 20 Hz to 22 kHz, +/- 0.3 dB @ 48 kHz sample rate
SNR and Dynamic Range:
-103 dB, A-weighted
THD+N: 0.002% @ -1dBFS, 1kHz
Signal Level: +3.4 dBu balanced
+1.2 dBV, unbalanced
Impedance: 20K Ohm balanced
10K Ohm unbalanced
Crosstalk:
< -100 dB @ 1 kHz
Headphone Outputs
Frequency Response: 20 Hz to 22 kHz, +/- 0.7 dB @ 48 kHz sample rate
SNR and Dynamic Range: 96 dB, A-weighted
THD+N: < 0.065% at maximum volume
Working Range: 24 to 600 ohms
Maximum Output Level: 0dbv into 32ohms
Crosstalk:
55 dB @ 1 kHz
Microphone Input
Pre-amp Gain: 60dB or greater
SNR (min gain):
-103 dB, A-weighted
Dynamic Range (min gain): 103 dB, A-weighted
THD+N (min gain): 0.003% @ -1dBFS
Freq. Response (min gain): 20 Hz to 22 kHz, +/- 0.1 dB @ 48 kHz sample rate
Sensitivity: +1dBu max level at min gain, +21dBu max level at min gain (pad engaged)
Phantom Power: 48 Volts DC no load, 16mA max
Switchable Pad:
-20 dB
Instrument Input
Pre-amp Gain: 0dB to 40dB or greater
Impedance: 1M Ohm unbalanced
SNR (min gain):
-103 dB, A-weighted
Dynamic Range (min gain): 103 dB, A-weighted
THD+N (min gain): 0.005% (-86 dB) @ -1 dBFS, 1 kHz
Freq. Response (min gain): 20 Hz to 22 kHz, +/- 0.3 dB @ 48 kHz sample rate
Maximum Input: +14dbv max level at min gain (pad disengaged)
Switchable Pad:
-20 dB
Power Requirements Power is derived from either the host computer’s USB bus or from the included 5VDC 2000mA power supply.
