M-Audio Fast Track Ultra User Manual

User Guide 11Fast Track Ultra
Output Channels
The right side of each Monitor tab provides level meters and faders for its corresponding stereo pair of outputs.
Each Monitor tab’s output faders control the output level sent to that pair of hardware outputs.
The Monitor tabs correspond to each pair of hardware outputs: Monitor outputs 1/2, 3/4, and 5/6 correspond to the
six analog outputs
16
. Monitor outputs 7/8 correspond to the S/PDIF digital outputs
21
.
Between the sixteen channel inputs and the two channel outputs is a Bypass button. Activating this button will
bypass the internal DSP effects, allowing you to monitor the channel returns without effects.
• NOTE: Only Monitor outputs 1/2 and 3/4 can utilize the internal DSP. Therefore the
Monitor mixer tabs for outputs 5/6 and 7/8 do not provide Bypass buttons.
Settings Tab
Sample Rate Settings
The up and down arrows select the current sample rate for the internal clock. Available sample rates are 44.1, 48,
88.2 and 96 kHz. The default sample rate is 44.1 kHz. Note that these arrows are disabled if Fast Track Ultra is set
to sync to external clock. See the section below on External Signal Status.

M-Audio Fast Track Ultra Specifications

General

Audio Interface Type	USB
Number of Mic Preamps	4
Analog Inputs	8
Analog Outputs	8
Digital Inputs	S/PDIF
Digital Outputs	S/PDIF
Phantom Power	Yes
Headphone Outputs	2
Sample Rate	96 kHz
Bit Depth	24-bit
Compatibility	Windows, macOS
MIDI I/O	Yes
