M-Audio Fast Track Ultra User Manual

User Guide 2Fast Track Ultra
2
3 Fast Track Ultra Features
‣ Two front-panel balanced/unbalanced Mic/Instrument Inputs on combo XLR/TS jacks
‣ Two front-panel balanced Mic inputs on XLR jacks
‣ Four Mic/Line input switches
‣ Four high-quality microphone preamps, based on M-Audio’s acclaimed Octane technology
‣ Six balanced/unbalanced line inputs on TRS jacks
‣ Six balanced/unbalanced line outputs on TRS jacks
‣ Two inserts on TRS jacks
‣ Phantom Power switch with front-panel indicator LED
‣ Stereo S/PDIF digital I/O on coaxial jacks
‣ Two stereo headphone jacks with individual level controls
‣ MIDI Input and Output with front-panel MIDI I/O indicators
‣ Two-color front-panel Signal/Clip indicators
‣ Supports sample rates up to 96kHz, with full 24-bit resolution
‣ Four mic pre input level controls with 20dB pads
‣ Output Level control for outputs 1/2
‣ Power LED
‣ Side-panel Kensington lock port
‣ Flexible routing with 16x8 internal mixer
‣ Onboard DSP effects
‣ Driver support for WDM/MME, ASIO2 (Windows XP, Windows Vista (32-bit editions))
and CoreAudio (MacOS X (v10.3.9 / 10.4.10 or later)
➤ IMPORTANT NOTE: Fast Track Ultra has been designed as a USB 2.0 device. It
may be used with a USB 1.1 port, but will then only function as a 2-in/2-out device with
sample rates limited to 44.1 and 48 kHz. This is due to the limitations of the USB 1.1
bus bandwidth.
➤ IMPORTANT NOTE: Fast Track Ultra can be powered via the included AC power
supply or via bus power from the host computer. However, when running on bus power,
Fast Track Ultra will be limited to four inputs and four outputs. These are mapped to
inputs 1/2, outputs 1/2, and the S/PDIF I/O.

M-Audio Fast Track Ultra Specifications

General

Audio Interface Type	USB
Number of Mic Preamps	4
Analog Inputs	8
Analog Outputs	8
Digital Inputs	S/PDIF
Digital Outputs	S/PDIF
Phantom Power	Yes
Headphone Outputs	2
Sample Rate	96 kHz
Bit Depth	24-bit
Compatibility	Windows, macOS
MIDI I/O	Yes
