Oxygen Keyboard Line User Guide
15
English
10 › Advanced Programming Functions
Introduction to Programming Options
MIDI CC (continuous controller) numbers are part of the General MIDI specification and are typically used to control the real-time
changing of parameters in musical equipment. For a complete list of standard MIDI controller numbers from 0 to 131, please see
Appendix A.
As mentioned in Section 6, many of the controls on the Oxygen range are fully programmable. This means that you can assign them
to send all sorts of different MIDI messages. This is achieved by selecting the controller for programming and assigning a 3-digit
number. Appendix A lists the numbers that can be assigned to different types of controllers on the Oxygen. It also defines the type of
MIDI message that will be sent out if you assign each number to a controller. As you can see from Appendix A, there is a wide variety
of MIDI messages that can be assigned to controllers. The uses of these messages will be explained in more detail in this section.
The assignable buttons and pedals have slightly different options from the faders or rotary dials.
The two charts show the transmit messages that can be programmed for each of the knobs, faders, and assignable buttons or
pedal.
Please pay extra attention to the differences between programming the faders or knobs and programming the buttons or pedal.
Faders and Rotary Dials:
MIDI CC Description Data 2 Data 3
0-119 Standard MIDI CC's Min Max
120-127 Channel Mode Messages Min Max
128 Pitch Bend Sensitivity
129 Channel Fine Tune
130 Channel Coarse Tune
131 Channel Pressure
132 RPN coarse RPN LSB RPN MSB
133 RPN Fine RPN LSB RPN MSB
134 NRPN Coarse NRPN LSB NRPN MSB
135 NRPN Fine NRPN LSB NRPN MSB
136 Master Volume GM*
137 Master Pan GM*
138 Master Coarse Tune GM*
139 Master Fine Tune GM*
140 Chorus Mod rate GM2*
141 Chorus Mod Depth GM2*
142 Feedback GM2*
143 Send to Reverb GM2*
144 Pitch Bend - -
255 Controller Off*** - -
