Assigning MMC Control to a Button
1. Select the button to control the MMC message.
2. Press the Advanced Function button.
3. Press the Control Assign key. Type the number 149 with the keypad, and confirm by pressing the Enter key.
4. Press the Advanced Function button.
5. Press the Channel Assign key.
6. Enter 127 using the key pad, then press Enter. This ensures all receiving devices will respond to the MMC message.
7. Press the Advanced Function button.
8. Press the DATA 2 key and enter a number from the chart below to select the MMC message you want. Finally, confirm your
selecting by pressing the Enter key.
Number MMC Command
01 STOP
02 PLAY
03 DEFERRED PLAY
04 FAST FORWARD
05 REWIND
06 RECORD STROBE
07 RECORD EXIT
08 RECORD PAUSE
09 PAUSE
10 EJECT
11 CHASE
12 COMMAND ERROR RESET
13 MMC RESET
Assigning RPN/NRPN to a Fader/Rotary Controller
Note: For a detailed description of RPN/NRPN data see the “MIDI Messages Explained” section.
1. Select the desired knob/fader as described earlier.
2. Press the Advanced Function button.
3. Press the Control Assign key. While the three display dots are visible, enter controller 132 for RPN Coarse, or 133 for RPN Fine, or
134 for NRPN Coarse or 135 for NRPN Fine using the numerical data entry keys. Press the Enter key to confirm your selection.
4. Press the Advanced Function button.
5. Press the DATA 3 key, and enter the desired number for the RPN/NRPN MSB. Press the Enter key to confirm.
6. Press the Advanced Function button.
7. Press the DATA 2 key, and enter the desired number for the RPN/NRPN LSB. Press the Enter key to confirm.
8. Press the Advanced Function button.
9. Press the Chan Assign Key, and enter a number from 1-16 to represent the MIDI channel you would like this message
transmitted on. Press the Enter key to confirm.
Many data sheets for synths make use of NRPN messages and will give the MSB and LSB values that should be entered for
Data
3 and Data 2 (See Appendix E). Some manuals may only give the hex values, but Oxygen requires the decimal value be entered.
Convert hexadecimal values to decimal values using the Windows or Mac calculator; select Scientific mode (Programmer mode on
the Mac), select Hex, then enter the hexadecimal value needed to convert. Press the Dec button to convert it to a decimal value.
Please reference Appendix C for more information.
Assigning a Note to a Button
The following shows the procedure for setting a button to transmit a MIDI Note On message when pressed, and a MIDI Note Off
message when released.
1 Press the Advanced Function button, then the CTRL ASGN key.
2 Enter “147” using the numerical data entry keys.
3 Press the Enter key to confirm.
This is the MIDI CC number that corresponds to Note On/Off mode (see Appendix A).
4 Press the Advanced Function button again followed by the Data 3 key.
5 Enter “100” using the numerical data entry keys.
6 Press the Enter key to confirm.
This means when you press the button, a Note On message is sent out with a velocity of 100.
