34
Roland GS / Yamaha XG Controller Chart
If you are using the Trigger Finger with a GS- or XG-compatible synthesizer or keyboard, you can use the following chart to access their deeper sound synthesis
parameters. The XG specification even provides control over each individual drum sound in a kit. To use these special parameters, first set the desired control on
the Trigger Finger to NRPN, then enter the MSB and LSB values below. For the drum parameters below, xx should be replaced with the note number of the drum
you want to control.
* Yamaha XG only
** Changed from ‘Delay’ to ‘Variation’ by Yamaha XG
Warranty Info
Warranty Terms
M-Audio warrants products to be free from defects in materials and workmanship, under normal use and provided that the product is owned by the original,
registered user. Visit www.m-audio.com/warranty for terms and limitations applying to your specific product.
Warranty Registration
Thank you for registering your new M-Audio product. Doing so immediately both entitles you to full warranty coverage and helps M-Audio develop and manufacture
the finest quality products available. Register online at www.m-audio.com/registe
r to receive FREE product updates and for the chance to win FREE M-Audio gear.
MSB LSB Parameter
1 8 Vibrato rate
1 9 Vibrato depth
1 10 Vibrato delay
1 32 Filter cutoff frequency
1 33 Filter resonance
1 99 Envelope attack rate
1 100 Envelope decay rate
1 102 Envelope release rate
20 xx Filter cutoff frequency of specified drum sound*
21 xx Filter resonance of specified drum sound*
22 xx Envelope attack rate of specified drum sound*
23 xx Envelope decay rate of specified drum sound*
24 xx Pitch coarse of specified drum sound
25 xx Pitch fine of specified drum sound*
26 xx Level of specified drum sound
28 xx Pan of specified drum sound
29 xx Reverb send level of specified drum sound
30 xx Chorus send level of specified drum sound
31 xx Variation send level of specified drum sound**
