Chapter 2: Controls and Connections
10
Venom User Guide
In Enable mode, the LED lights to indicate that the associated part is enabled. Pressing any Multi Part button
enables (or disables) the corresponding part.
You can press more than one Multi Part button simultaneously to Select, Enable, or Mute (or deselect, disable,
or unmute) those parts.
When MIDI data is received on a part, the associated LED flashes briefly, regardless of the Multi Control mode.
Edit
The Edit button sends an “all notes off” message and a “reset all controllers” message to all 16 MIDI channels.
Press the Edit button to enable Global mode, and then press the corresponding key on the keyboard to execute
the desired command (such as toggling Local Control On or Off). The LED of the Edit button flashes slowly
while in Global mode. For more information about Global mode, see “Using Global Mode” on page 23. Also
see “Global Editor” on page 77.
Front Panel Connector
Headphone Output
Connect your headphones to the 1/4” stereo jack on the front of Venom. Use the Master Volume control to
adjust the volume for your headphones.
Figure 2. Venom front panel
