M-Audio Venom User Manual

Appendix A: MIDI Specifications
85
Venom User Guide
Modulation Matrix Access
Message [H] MIDI [Hex] Description
NRPN 0180H -
NRPN 018FH
Bn 63 03, 62 00, 06 vv
Bn 63 03, 62 0F, 06 vv
Set Modulation Target on Node 1-16:
0:LFO3 Rate, 1=Cutoff, 2=Pitch, 3=OSC1 Pitch, 4=OSC2 Pitch, 5=OSC3
Pitch
6=Amplitude, 7=FilterQ, 8=Ringmod, 9=ExtIn, 10=FM Amount,
11=OSC1 PWM, 12=LFO1 Rate, 13=LFO2 Rate, 14=OSC Detune,
15=OSC1 Vol, 16=OSC2 Vol, 17=OSC3 Vol,
64:Modulate Node 1, 65:Modulate Node 2, ...79:Modulate Node 16
NRPN 01A0H -
NRPN 01AFH
Bn 63 03, 62 20, 06 vv
Bn 63 03, 62 2F, 06 vv
Set Modulation Soure on Node 1-16:
0:None, 1:EG1, 2:EG2, 3:EG3, 4:EG1rel, 5:EG2rel, 6:EG3rel,
7:LFO1, 8:LFO2, 9:LFO3, 10:LFO1un, 11:LFO2un, 12:LFO3im,
13:LFO1lo, 14:LFO2lo, 15:LFO3lo, 16:LFO1unlo, 17:LFO2unlo,
18:LFO3unlo,
19:Velocity, 20:Velocity (negative), 21:Key, 22:ModWheel, 23:PitchBend
24:ChnTouch, (25:PolyTouch), 26:Expression, (27:Sustain), (28:Porta-
mento)
29:Control1, 30:Control2
NRPN 01C0H -
NRPN 01CFH
Bn 63 03, 62 40, 06 vv
Bn 63 03, 62 4F, 06 vv
Set Modulation Depth on Node 1-16
For Pitch modulations the following values provide proper tune scaling
(values in octaves):
0:neutral, 127=+2, 110=+1, 95=+1/2, 83=+1/4, 45=-1/4, 22=-1/2,
18=-1, 0=-2

M-Audio Venom Specifications

General

Synthesis Type	Virtual Analog
Polyphony	12 voices
Oscillators	3 per voice
Arpeggiator	Yes
Headphone Output	1 x 1/4" TRS
Effects	Distortion, delay, reverb, chorus, phaser
Keyboard	49 keys
MIDI	In, Out, USB
Audio Outputs	2
