11
install the washer legs
1. Carefully tilt the washing machine to the back and install the bot-
tom legs at the front of the base. Make sure that the legs are in-
stalled in place. (Figure 1).
2. Carefully tilt the washing machine to the front and install the bot-
tom legs at the back of the base. Make sure that legs are installed
in place. (Figure 2).
Figure 1 Figure 2
install the water inlet hose
On models so equipped, insert the water inlet hose into the water-
inlet port on the control panel.
Make sure the end of the inlet hose that has a couple is firmly
seated in the water inlet port. Otherwise there could be water leaks
that can damage the washer.
