17
Assemble
Disassemble
Lint filter front cover
Lint filter
back cover
once the wash is completed
After each use, be sure to clean the lint as well as any foreign mate-
rials from the lint filter and the overflow filter. Removing lint is im-
portant for the good operation of the machine.
WARNING: UNPLUG THE WASHER FROM THE
POWER SUPPLY BEFORE PERFORMING ANY
CLEANING OR SERVICE JOB.
cleaning the lint filter
THE LINT FILTER MUST ALWAYS BE USED DURING WASHING AND
SHOULD BE CLEANED AFTER EACH USE.
1. To remove the lint filter, first press the elastic piece at the top end
of the filter to release the tab from the filter cover, then pull out-
ward.
2. Pull out the bottom end of the lint filter to separate it from the
lint filter front cover. Remove lint completely by rinsing with clear
water.
3. Assemble and reinstall the lint filter.
