Product functions
MHTP24EB by MacAllister
GB
IE
In more detail...
13
Handle controls
There are three controls at the handle (16)
with the following functions.
> The ignition switch (14) enables the
manual starting or the stopping of the
engine.
> The throttle interlock (13) prevents
unintentional activation of the throttle
trigger until manually released.
> Adjust the engine speed with the throttle
trigger (12).
Starting / Stopping
Starting
> Place the product on a at, stable
surface. Ensure that the cutting device
in use does not touch the ground or any
objects.
> Set the ignition switch (14) to its on
position “I” (Fig. 8) (cold or warm
starting).
If the engine is cold:
> Move the choke lever (8) to the “CLOSED” position and
depress the primer (9) 7 - 10 times until fuel is visible (Fig. 9).
9 8
9 8
Fig. 9 Fig. 10
1.
2.
3.
14
13
12
Fig. 7
14
Fig. 8
Fig. 9 Fig. 11
