Mac allister MLMP300H40 - Product Identification and Parts; Lawnmower Component Diagram and List

12 13
MLMP300H40 MLMP300H40
Getting Started . . . Getting Started . . .
25
24
24a
24b
24
24d
24e
24c
1. Handle
a. Transportation handle
2. Brake clutch
3. Upper handle bar
4. Lower handle bar
5. Brake wire
6. Side lever (x2)
a. Washer *
b. Bolt *
7. Wire clip
8. Air vents
9. Fuel tank cap
10.
a. Filter *
b. Cover *
11. Primer
12. Water hose connector
13. Spark plug connector
14. Wheel
15.
16. Oil tank cap with dipstick
17. Lever for cutting height adjustment
18. Lower handle bar lock
19.
20. Grass catcher
a. Handle
b. Hatch
21. Starter wire
22. Hook for recoil starter handle
23. Recoil starter handle
24. Cutting means (blade)
a. Spindle
b. Ring
c. Washer
d.
e. Hex bolt
25. Rear discharge chute
26. Mulching insert
a. Unlock button
27. Spark plug wrench
28. Operator’s manual of the
BRIGGS&STRATTON engine
NOTE: Parts marked with * are not shown in this overview. Refer to the
respective section in the instruction manual.
10
1a
14
15
18
20
9
16
1
6
13
19
22
23
8
5
6a
6b
2
3
21
4
11
7
17
12
20a
20b
Your productYour product
