In more detail . . .
In more detail . . .
Underbody and cutting means
WARNING! Wear protective gloves when working on the cutting means
(24) and close to it! Use proper tools to remove debris, e.g. a wooden stick!
Never use your bare hands!
Always use original spare parts for replacement. The cutting means (24)
must be replaced by an identical type with the reference number
Do not attach any other type of cutting means (24) !
The replacement of the cutting means (24) should be done by an experienced
operator! Rework or sharpening blades is not recommended unless it is done
NOTE: We strongly recommend jacking the product when performing
inspection and work on the cutting means (24). Avoid tilting the product in
order to prevent fuel and oil leakages.
1.
Keep the underbody and cutting means (24) clean and free of debris. Remove
clippings from the rear discharge chute (25).
2.
Check all nuts and bolts periodically for tightness before the operation. After
prolonged use, especially in sandy soil conditions, the cutting means (24) will
reduced, and the cutting means (24) should be replaced.
3.
Keep the cutting means (24) sharp to ensure a good cutting performance. Replace
a worn or damaged cutting means with a new one of the same type or have it
4.
If jacking the product is not possible, tilt it to the right side so that the fuel tank
cap (9) side is up. This helps to prevent fuel leakage and harder starting due to
5.
Loosen the hex bolt (24e) anti-clockwise and remove it together with the
24d), washer (24c) cutting means (24), and ring (24b) (Fig. 27).
6.
Replace the cutting means (24) with a new one of the same type. Slide the ring
(24b) into the slot on the spindle (24a 24),
24d) and hex bolt (24e). Tighten the hex bolt clockwise
with 40-45 Nm force to ensure safe operation of the product (Fig. 27).
DANGER! If the cutting means (24) are not torqued properly, they could
become loose and be thrown from the product and seriously hurt or kill the
operator or bystanders.
Maintenance table with schedules
Part To do Before/
after
each
use
First
month
or
5 hours
Every
3 months
or
25 hours
Every
6 months
or
50 hours
Every
year
or
100 hours
Every
2 years
or
250 hours
Engine oil
check x
replace x
check x
clean x
replace x
Spark plug
check/adjust x
clean x
replace x
Spark plug cap clean x
Fuel tank clean x
Fuel tube clean Every 2 years (replace if necessary)
Cutting means replace
Replace the cutting means (24) after 50 hours of mowing, or 2 years whichever is
sooner regardless of condition.
Care and maintenance Care and maintenance
DAYE 2105200264.
