OPERATOR'S STATION
Symbol Definitions (continued)
- Conveyor speed
- Engaged
- Disengaged
- Header drive
- Header height
- Increase
- Decrease
- Reel height
- Deck shift
- Speed range control
High Low
- On
- Bypass
- Header express down
option
- Header tilt up
- Header tilt down
- Reel forward
- Reel aft
- Seatback angle
- Seat fore-aft
- Seat height
- Seat fore-aft isolato
r
lockout
- Cigarette lighte
r
