OPERATION
Driving the Windrower (continued)
TO DRIVE REARWARD
:
WARNING: Back up slowly. Steering
is opposite to normal when
reversing. Hold steering wheel at the
bottom and turn wheel in direction you want
the rear of the machine to travel.
1. Move speed-range switch (A) to field position L
(dual speed units).
2. Move throttle lever to a mid-range position (B).
NOTE: Reversing in low speed-range and at
reduced engine speed is recommended since
steering will be less sensitive than at higher speed
settings.
CAUTION: Check again to be sure all
bystanders have cleared the area.
3. Move variable ground speed lever (C) rearward
to desired speed.
STEERING OPPOSITE TO NORMAL
WHEN REVERSING
A
B
C
CONTROL LEVERS - DRIVING REARWARD
