10
Rear panel interfaces
Volume control on these inputs is controlled by the Master volume control.
OUTPUT SECTION
Master volume
Adjusts the master output signal from - ∞ to 0 dB.
Mix out
This output enables link of the mixed signal microphone/line signal to other M•Flex
boxes. Note that normally, a link output will only allow for a few boxes to be linked,
before the quality of the signal is reduced. In the M•Flex speakers, an active line
driver operates the link output, so an unlimited number of M•Flex speakers can be
linked while perfect signal quality is maintained.
Bass
Adjust the bass output of the speaker (Shelv - 100 Hz +- 10 dB)
Treble
Adjust the high frequency output of the speaker (Shelv – 10 kHz +- 10 dB)
