DLM8 & DLM12
2000W
Powered Loudspeakers
DLM8/12 LOUDSPEAKER SPECIFICATIONS
Acoustic Performance
Frequency Response (–10 dB) 65 Hz – 20 kHz [DLM8]
38 Hz – 20 kHz [DLM12]
Max peak SPL (@ 1m calculated)
1
125 dB [DLM8]
128 dB [DLM12]
Crossover Point 1.6 kHz
Dispersion 90˚ conical
Equalization
Low Shelving ±15 dB @ 80 Hz
Mid-Peaking ±15 dB @ 2.5 kHz
High Shelving ±15 dB @ 12 kHz
Increments ±3 dB
High-Frequency Section
Voice Coil Diameter 1.75 in / 44 mm
Horn Entry Diameter 1.0 in / 25 mm
Diaphragm Material Polyimide Film
Magnet Material Ferrite
Low-Frequency Section
Woofer Diameter 8.0 in / 203 mm [DLM8]
12.0 in / 305 mm [DLM12]
Voice Coil Diameter 2.0 in / 51 mm [DLM8]
2.5 in / 64 mm [DLM12]
Diaphragm Material Paper
Magnet Material Ferrite
1
Calculated from driver sensitivity and amplifier power.
Power Amplifiers
System Power Amplification
Rated Power 1000 watts rms
2000 watts peak
Low Frequency Power Amplifier
Rated Power 500 watts rms
1000 watts peak
Rated THD < 1%
Cooling Multi-speed fan
Design Class D
High Frequency Power Amplifier
Rated Power 500 watts rms
1000 watts peak
Rated THD < 1%
Cooling Multi-speed fan
Design Class D
DL2 Digital Mixer System Processing
EQ Six speaker modes
Alignment Delay 0-300 ms
FX 16 presets
Multi-band feedback destroyer On / Off / Clear / Hold
Memory Three locations for
instant venue setting
recall and factory reset
Input / Output
Channel 1
Mic 3.3 k
balanced
Line 20 k
balanced
10 k
unbalanced
1/4" TRS 16 k
balanced
8 k
unbalanced
Channel 2
XLR Line 20 k
balanced
10 k
unbalanced
1/4" TRS [Hi-Z instrument] 1 M
unbalanced
RCA 25 k
unbalanced
Thru Male XLR balanced
