Acoustic Performance:
Frequency Response (–10 dB) 57 Hz – 20 kHz
Frequency Response (–3 dB) 65 Hz – 18 kHz
Max peak SPL (calculated)
1
134 dB
Max peak SPL (measured)
2
124 dB
Crossover Point 2.0 kHz
Array Coverage
Horizontal Coverage (–6 dB) 110˚ averaged
2 kHz to 10 kHz
Vertical Coverage (–6 dB)
1x HDA 20˚ averaged
2 kHz to 10 kHz
2x HDA 40˚ averaged
2 kHz to 10 kHz
3x HDA 60˚ averaged
2 kHz to 10 kHz
4x HDA 80˚ averaged
2 kHz to 10 kHz
Input / Output
Input Type Female XLR balanced
Input Impedance 11 k
balanced
Loop Out Male XLR balanced
Voicing Mode
1-2 Voicing for an array
with 1 or 2 HDAs
3-4 Voicing for an array
with 3 or 4 HDAs
3-4 Long Throw Long Throw Voicing
for an array with
3 or 4 HDAs
*See pages 13-14 and the Frequency Response graph on page
28 for more information.
1 Calculated from driver sensitivity and amplifi er power.
2 Measured with pink noise, free fi eld at 1 meter, before limiting.
Low-Frequency Power Amplifi er
Rated Power 500 watts rms
1000 watts peak
Rated THD < 0.03%
Cooling Convection Extrusion
Design Class D
High-Frequency Power Amplifi er
Rated Power 100 watts rms
200 watts peak
Rated THD < 0.03%
Cooling Convection Extrusion
Design Class D
Low-Frequency Transducer
Diameter 12.0 in / 305 mm
Voice Coil Diameter 3.0 in / 76 mm
Diaphragm Material Paper
Magnet Material Neodymium
High-Frequency Transducer x2
Voice Coil Diameter 1.7 in / 43 mm
Horn Entry Diameter 0.75 in / 18 mm
Diaphragm Material Mylar
Magnet Material Neodymium
Line Input Power
US 100 – 120 VAC, 50 – 60 Hz, 200W
EU, CN 200 – 240 VAC, 50 – 60 Hz, 200W
AC Mains Connector Locking Neutrik PowerCon
®
A
20 amp, 250 VAC
Max input 800W
AC Mains Cable (included) 9.5 ft / 2,896 mm
AC Loop Connector Locking Neutrik PowerCon
®
B
20 amp, 250 VAC
Max output 600W
AC Loop Cable (included) 1.5 ft / 457 mm
HDA Specifi cations
Appendix D: Technical Information
25
